SC To ST/UPC OM4 Multimode Simplex Fiber Optic Patch Cable PVC/LSZH
Violet Patch Cord
Range of Mode | Single mode or Multi mode |
Cable Type | Simplex, Duplex Ziocord. or Multi-cores |
Connector Style | SC, FC, ST, LC, MTRJ, E2000, MU, MPO /MTP.etc |
Polish or Ferrule Interface Type | PC, UPC, APC |
Cable Diameter | 0.9mm, 1.2mm, 1.6mm, 1.8mm,2.0mm, 3.0mm |
Outer Jacket | PVC /LSZH/OFNP |
Jacket Color | SM Yellow | OM1, OM2 Orange | OM3 Aqua | OM4 Aqua or Violet | OM5
Lemon Green |
Durability | 500 cycles(0.2 dB max increase). 1000mate/de mate cycles |
Operating Temp. | -25℃ to +70℃ |
Storage Temp. | -40℃ to +85℃ |
SC-ST Optical Fiber Patch Cord Single Core Single Mode .
APPLICATION:
• Smiton's optical fiber patch cord used as cross-connect jumpers,
equipment and work area cords in fiber 0ptic telecommunications and
FTTH (Fiber To The Home);CATV & CCTV;Data Processing Networks
• Mechanical
Connector ferrule: ceramic
End-face radius of curvature: 10 mm < R < 30 mm
Apex offset: < 50 μm
Cable material: PVC
Operation temperature: -20 °C to +70 °C
Connector Type | Performance Level |
Standard | Elite |
Connector | Mode | Endface | IL(dB) | RL(dB) | IL(dB) | RL(dB) |
LC/SC/FC/ST | SM | PC | ≤0.2 | ≥50 | ≤0.15 | ≥50 |
UPC | ≤0.2 | ≥55 | ≤0.15 | ≥55 |
APC | ≤0.2 | ≥60 | ≤0.15 | ≥60 |
MM | PC | ≤0.2 | ≥35 | ≤0.15 | ≥35 |
MPO/MTP | SM | APC | ≤0.7 | ≥60 | ≤0.35 | ≥60 |
MM | PC | ≤0.5 | ≥20 | ≤0.35 | ≥20 |
MTRJ | SM | PC | ≤0.5 | ≥50 | / | / |
MM | PC | ≤0.5 | ≥35 | / | / |
Our Value:
Initiative, Hard working ,Efficiency,Innovation, Grateful, Sharing.
Our Philosophy:
Professional casts quality,cooperation makes win-win future.
Our Solutions:
Fastest, Effective, Reliable, Flexible And Professional OEM/ODM
Solutions.
Our Certificate:
ISO9001:2015, ISO14001:2015,OHSAS18001:2007 etc.
Our Team:
We serve our every customer with fastest and most professional
response.
Our Patents:
We have 20 patents and we'll go on creating new products to master
latest market trend.
