24ports UTP RJ45 1U Blank Unloaded Patch Panel

24 port unshielded cat5e network distribution frame 19" 1U cat5e UTP patch panel
1. Product Name:Cat5e Patch Panel
2. Product Type: Cat5e 24-port patch panel, unshielded
3. Specifications: 19′′ installation size
4. Material: injection molded with high quality cold rolled steel, phosphor bronze and PC
5. Color: Black
6.Main technical parameters
* IDC: Phosphor bronze, silver plated (20~50uiLZh), suitable for cables of 22, 24 and 26AWG (0.64, 0.5 and 0.4mm), with a life of not less than 250 times.
* 8-line pin: phosphor bronze, gold-plated (20~50uiLZh), plug and socket can be re-plugged no less than 750 times
* Flame retardant: injection molded with PPO+PC to meet international standards
* Contact resistance: no more than 2.5mΩ under normal atmospheric pressure (without body resistance)
* Insulation resistance: not less than 1000MΩ under normal atmospheric pressure conditions
* Electrical strength: DC 1000V (AC, 700V) No breakdown and arcing in 1 minute
* Standard: Designed and manufactured according to international standard ISO/IEC11801; TIA/EIA568

Shenzhen ADTEK Technology Co., Ltd. was established in 2007, engaging in providing complete and high-performance fiber optic products and premise distribution solutions for customers worldwide. During these years, we have been continually growing and expanding our product line to keep up with the pace of industry trends.

From ADTEK you can get the right solutions to fiber optic and premise infrastructures. Our products include fiber optic patch cords, connectors and adapters, patch panels, Cat5e & Cat6 LAN cables, patch cords, patch panels and keystone jack products.

Our knowledgeable sales, technical supporters and engineering staff are dedicated to understanding our customers' requirements and designing products & solutions that meet their needs. In addition, ODM services are well provided for our clients. We help you stay competitive by constant innovation services.
